Captor Double Wall Containment
Snyder's revolutionary Captor Containment System is designed to alleviate the ever-changing environmental and safety concerns regarding bulk chemical storage and containment for the 21st century
Captor's unique tank-in-a-tank design enables users and specifiers to incorporate advance performance and safety features on a bulk-handling system, which provides total containment protection. Captor's double wall construction is completely enclosed so that external matter, such as dust, rain and snow is prevented from collecting in the outer containment tank.

Besides delivering unparalleled performance benefits, Captor Containment Systems also contribute to your company's bottom line by significantly reducing installation and procurement cost. Every Captor is shipped fully-assembled on either a standard or wide load flat bed trailers, which reduces comparable costs by an average of 35 percent
Double Wall Tank Systems
Snyder’s latest product innovation, double wall tanks ranging from 35 gallons up to 500 gallons, provides a secondary containment solution in one integral space saving unit.
The smaller design configurations are ideal for commercial “Day” tank system requirements, and can be used in conjunction with Snyder’s extensive line of larger double wall Captor Containments.

Patent #6474496 applies to the Captor & Dual Containment Tanks


8700 & 10,000 gallon Captors
Now Available!



How the Captor Containment Fits Together
Tank dimensions may vary depending on manufacturing location - please contact factory for drawing specific to the F.O.B. location. Specifications Subject to Change Without Notice.
NOTE: Dimensions listed below and on drawings may vary +/- 3% (standard rotational molding tolerance).

Part Number CAPTOR or DUAL CONTAINMENT Diameter Height F.O.B.
1010100N-- 15 GALLON DCT-ST* 23 23 C
1010300N-- 30 GALLON DCT-ST* 23 35 C
1000200N-- 35 GALLON DCT 22 36 M
1010500N-- 55 GALLON DCT-ST* 28 36 C
1000300N-- 60 GALLON DCT 26 41 M
1010700N-- 100 GALLON DCT-ST* 33 44 C
5980000N-- 120 GALLON DCT 34 49 M
1010900N-- 140 gallon dct-st* 32x32 48 C
1000400N-- 150 GALLON DCT 34 60 M
1000500N-- 275 GALLON DCT 47 60 L
1000600N-- 360 GALLON DCT 53 60 L
1000800N-- 500 GALLON DCT 53 79 L
5040000N-- 550 GALLON 76 65 L
5470000N-- 1100 GALLON 76 104 L
5490000N-- 1550 GALLON 76 136 L
5570000N-- 2000 GALLON*** 102 103 L,P
5580000N-- 2500 GALLON*** 102 122 L,P
5590000N-- 3000 GALLON*** 102 142 L,P
5600000N-- 3500 GALLON*** 102 158 L,P
5610000N-- 4000 GALLON*** 102 178 L,P
5620000N-- 4500 GALLON 102 197 L
5630000N-- 5000 GALLON  102 216 L
5660000N-- 5500 GALLON  120 172 L
5670000N-- 6500 GALLON  120 199 L
1006400N-- 8700 GALLON 142 197 L
1006600N-- 10,000 GALLON 142 226 L
Tanks available in 1.5 and 1.9 Specific Gravity in HDLPE and XLPE materials. Contact Factory for availability.

15-2500 Gallon Systems have a standard secondary outer containment manufactured from HDLPE, Natural, 1.9 specific gravity.
*DCT-ST systems can only have top fittings installed.  No sidewall fittings can be installed.

ACCESSORIES FOR CAPTOR CONTAINMENT SYSTEMS only Part Number ****does not include fitting****  Patent Pending
1070000N-2E U.F.O.TRANSITION FOR 2" BOLTED FITTING - EPDM GASKET
1070000N-2V U.F.O.TRANSITION FOR 2" BOLTED FITTING - VITON GASKET
1070000N-3E U.F.O.TRANSITION FOR 3" BOLTED FITTING - EPDM GASKET
1070000N-3V U.F.O.TRANSITION FOR 3" BOLTED FITTING - VITON GASKET
1070000N-4E U.F.O.TRANSITION FOR 4" BOLTED FITTING - EPDM GASKET
1070000N-4V U.F.O.TRANSITION FOR 4" BOLTED FITTING - VITON GASKET
1070100N-6E U.F.O. TRANSITION FOR 6" BOLTED FITTING - EPDM GASKET
1070100N-6V U.F.O. TRANSITION FOR 6" BOLTED FITTING - VITON GASKET
Note:  UFO Transition for 6" bolted fitting is only available on the 8700 and 10,000 gallon size Captors.
ADDITIONAL ACCESSORIES
Part Number
3471030 LEAK DETECTION SENSOR
3470515 ULTRASONIC LEVEL INDICATOR - PVC
347-- 2" PVC SIGHT GLASS ASSEMBLY W/BOTTON TEE
347-- 3" PVC SIGHT GLASS ASSEMBLY W/BOTTOM TEE
347-- SEISMIC RESTRAINTS - 550 - 10,000 GALLON
347-- REVERSE LEVEL GALLONAGE INDICATOR
347--* 2" EXTERNAL FILL PIPE ASSEMBLY
347--* 3" EXTERNAL FILL PIPE ASSEMBLY
347--* 4" EXTERNAL FILL PIPE ASSEMBLY
*includes 1 PVC/CPVC Adapter, f ft. Schedule 80 PVC/CPVC Pipe, 2 90 degree elbows, 1 FRP Strut Assembly
F.O.B :  L = Lincoln, Nebraska; M = Marked Tree, Arkansas; P = Philippi, West Virginia; C = Chowchilla, California

Rain Water Collection Tanks

Amprotec water tanks are tough and can be easily installed. We manufacture rain water collection tanks both for domestic and commercial purpose. Our sleek design and unique models make your water storage pretty easy. We will give you solution for efficient portable water storage. Our tanks are durable, long lasting and effective that makes our company #1 today.

Our water storage tanks offer solution for both residential and commercial needs. We are specializing in rainwater systems that can supply a household with all the water needs.

Amprotec has the experience of manufacturing high strength and light weight water tanks over so many years. We develop ideal tanks for all of your household needs.

We both manufacture above ground and underground water storage tanks. These are widely used for the collection and storage of rain water.
